Name: Pioneer® Multi Zone 18,000 BTU Diamante Ultra Indoor Section 21.5 SEER 230V Ductless Mini-Split Wi-Fi Inverter++ Air Conditioner Heat Pump
SKU: 741
Price: 750.00 CAD
Availability: InStock

Description

Summary

OUTDOOR SECTION ONLY for Dual (2) Zone
Ultra High Efficiency DC Inverter++ version
Cooling capacity: 18,000 BTU/H Nominal (Range: 4,950 MIN ~ 23,000 MAX) with 21.5 SEER efficiency
Heating capacity: 19,000 BTU/H Nominal (Range: 4,900 MIN ~ 23,000 MAX) with 10.6 HSPF efficiency
Voltage: 208~230 V, 60 Hertz, 1 Ph
Factory charged for up to 25’ line set per circuit
Energy-Star Certified
Whisper Quiet Operation

Refrigerant

R410A Pre-Charged Outdoor Unit, accommodating refrigerant line lengths up to 25 ft. per circuit.

Technical Information

Power Supply: 208~230V, 60Hz, 1Ph
Communication Protocol: Current Loop
Min-Max Load Attached: 12,000~24,000 BTU/h
Cooling Rated Capacity: 18,000 BTU/h
Cooling Capacity Range: 4,950~23,000 BTU/h
Cooling SEER (Ductless): 21.5 BTU/w
Heating Rated Capacity: 19,000 BTU/h
Heating Capacity Range: 4,950~23,000 BTU/h
Heating HSPF (Ductless): 10.6 BTU/w
Refrigerant Type: R410a
Suitable Area: 600~800 Sq.F
Sound Level: 59.5 dB(A)
Net Dimensions (WDH): 35 x 13.5 x 26.5 Inches
Carton Dimensions (WDH): 40.5 x 17.25 x 29.5 Inches
Net / Gross Weight: 100 / 109 Lbs
Matching Indoor Models

Dual Zone Combinations

Rating Two Units

Wall: 9 + 9 9 + 9

Ducted: 9 + 9 9 + 12

12 + 12

9,000 BTU Compatible Units
- Wall Mounted: WS009GMFI22HLE (30.3 x 11.8 x 21.8 inches)
- Cassette: CB009GMFILCFHD (22.5 x 22.5 x 10.3 inches)
- Concealed Ducted: RB009GMFILCFHD (27.5 x 25.0 x 8.3 inches)
12,000 BTU Compatible Units
- Wall Mounted: WS012GMFI22HLE (31.5 x 13.2 x 21.7 inches)
- Cassette: CB012GMFILCFHD (22.5 x 22.5 x 10.3 inches)
- Floor-Ceiling: FB012GMFILDFHE (27.5 x 23.6 x 8.3 inches)
- Concealed Ducted: RB012GMFILDFHD (27.5 x 25.0 x 8.3 inches)
Min. / Max. Loading
12,000 / 24,000 BTU/h.
Notes
Every indoor unit attached will operate at a random, self regulated capacity, based on the actual demand it measures from the zone it is serving (Between 30% to 100% of its rated capacity or OFF). Outdoor unit will also self regulate its output capacity, based on the total demand it reads from all of the simultaneously running indoor units at any given moment. With multi split systems, the total demand from the outdoor unit, shall seldomly exceed 67% of the total available capacity of the combined indoor unit group due to load fluctuations. Although very seldom, if and when the total demand from the combined indoor group exceeds the rated capacity of the outdoor unit, the capacity of the each indoor unit will be annotated accordingly. For high demand heating applications, max loading limits may need to be reduced by 10-15 % to avoid under-performance risks at some extreme conditions.
